Slim series wireless furnace temperature tester

Category： Slim Series Wireless Furnace Temperature Tester

Introduction to Slim series wireless furnace temperature tester Product name：Introduction to temperature testerProduct model: SlimSTART /Slim2000Number of channels：6/9/12 channelsSlim series furnace temperature tester is a revolutionary testing instrument. The software is now updated to Profiling Software. At the same time, more process curve application projects will be added to the existing foundation, providing users with easier work requirements。Model:SlimSTART/Slim2000Measurement range:-150-1050（℃） Temperature measurement resolution:0.1℃ External dimensions: 6channels:200*78*20(mm) 9channel

DESCRIPTION

Introduction to Slim series wireless furnace temperature tester

Product name：Introduction to temperature tester

Product model: SlimSTART /Slim2000

Number of channels：6/9/12 channelsSlim series furnace temperature tester is a revolutionary testing instrument. The software is now updated to Profiling Software. At the same time, more process curve application projects will be added to the existing foundation, providing users with easier work requirements。

Model:SlimSTART/Slim2000

Measurement range:-150-1050（℃）

Temperature measurement resolution:0.1℃

External dimensions: 6channels:200*78*20(mm)

9channels:200*78*20(mm)

12channels:200*101*20(mm)

Product features:

1. Automatic thermocouple position setting import

2. Automation of temperature curve evaluation

3. Automatic visualization operation instructions

4. When the instrument overheats or the battery level is too low, it will automatically give an indication and stop the temperature curve test.

5. Automatic retrieval can ensure the integrity of temperature curve data.

6. The stability of the production process is automatically confirmed.

7. Standard USB-Type+Bluetooth wireless transmission (capable of wireless data download, wireless real-time telemetry, and barrier free distance of 100 meters)

8. Equipped with a dedicated high-temperature resistant rechargeable battery, it can work continuously for more than 15 hours on a single charge

9. Dedicated data, Bluetooth, charging status indicator light, and clear instrument working status at a glance

Product specifications:

accuracy :	+/-1.2℃

Resolution:	0.3 ℃ ～ 0.1 ℃

Internal operating temperature:	0 ℃ ～105 ℃

Applicable thermocouples:	6/9/12 K-type thermocouple

Measuring temperature range:	-150℃ ～1050 ℃

System compatibility:	personal computer

communication mode	Standard USB Type+Bluetooth wireless transmission
Power requirements:	5V (standard USB interface, 500Ma)

Size (equipped with standard insulation sleeve):	L :280 * W :86 * H: 26 (mm) 6/9 channels L : 280 * W: 108 * H: 26 (mm) 12 channels
Minimum System Requirements	400MHz processor, 1GB of usable hard disk storage, 1024 * 768 resolution/16-bit, Microsoft ® Windows ® 2000 or XP ³
